THRU AXLE CENTER LOCK SERIES

  •   CENTER LOCK SERIES
      TC-712 TXC-142S
    SPECIFICATION
    F/R F R
    HOLE COUNT 24/28H 28H
    GAUGE 14 14
    O.L.D. 100MM 142MM
    AXLE LENGTH Ø12 Ø12
    QR N/A N/A
    WEIGHT 120G 335G




    TC-712
    TXC-142S

  •   CENTER LOCK SERIES
      TXC-142A
    SPECIFICATION
    F/R R
    HOLE COUNT 28H
    GAUGE 14
    O.L.D. 142MM
    AXLE LENGTH Ø12
    QR N/A
    WEIGHT 280G




    TXC-142A

  •   CENTER LOCK SERIES
      CL-712 CL-71Q
    SPECIFICATION
    F/R F F
    HOLE COUNT 24/28/32H 24/28/32H
    GAUGE 14 14
    O.L.D. 100MM 100MM
    AXLE LENGTH Ø12 108MM
    QR N/A N/A
    WEIGHT 150G 153G




    CL-712
    CL-71Q

  •   CENTER LOCK SERIES
      RXC-142S RXC-142A
    SPECIFICATION
    F/R R R
    HOLE COUNT 24/28/32H 24/28/32H
    GAUGE 14 14
    O.L.D. 142MM 142MM
    AXLE LENGTH Ø12 Ø12
    QR N/A N/A
    WEIGHT 355G 305G




    RXC-142S
    RXC-142A

  •   CENTER LOCK SERIES
      CL-25 CL-26
    SPECIFICATION
    F/R F R
    HOLE COUNT 24/28/32H 24/28/32H
    GAUGE 14 14
    O.L.D. 100MM 135MM
    AXLE LENGTH 108MM 145MM
    QR N/A N/A
    WEIGHT 175G 400G




    CL-25
    CL-26

  •   CENTER LOCK SERIES
      CL-2611
    SPECIFICATION
    F/R R
    HOLE COUNT 24/28/32H
    GAUGE 14
    O.L.D. 135MM
    AXLE LENGTH 145MM
    QR N/A
    WEIGHT 400G




    CL-2611

THRU AXLE 6 BOLT DISC SERIES

  •   6 BOLT DISC
      TD-712 TX-142A
    SPECIFICATION
    F/R F R
    HOLE COUGE 24/28H 24/28H
    GAUGE 14 14
    O.L.D. 100MM 142MM
    AXLE LENGTH Ø12 Ø12
    QR N/A N/A
    WEIGHT 140G 288G




    TD-712
    TX-142A

  •   6 BOLT DISC
      RX-812 RX-81Q
    SPECIFICATION
    F/R F F
    HOLE COUNT 24/28/32H 24/28/32H
    GAUGE 14 14
    O.L.D. 100MM 100MM
    AXLE LENGTH Ø12 108MM
    QR N/A N/A
    WEIGHT 145G 148G




    RX-812
    RX-81Q

  •   6 BOLT DISC
      RX-300 RX-301
    SPECIFICATION
    F/R R R
    HOLE COUNT 24/28/32H 24/28/32H
    GAUGE 14 14
    O.L.D. 142MM 142MM
    AXLE LENGTH Ø12 Ø12
    QR N/A N/A
    WEIGHT 300G 296G




    RX-300
    RX-301

  •   6 BOLT DISC
      RX-512
    SPECIFICATION
    F/R F
    HOLE COUNT 28H
    GAUGE 14
    O.L.D. 100MM
    AXLE LENGTH Ø12
    QR N/A
    WEIGHT 227G




    RX-512

  •   6 BOLT DISC
      RX-25 RX-26
    SPECIFICATION
    F/R F R
    HOLE COUNT 24/28/32H 24/28/32H
    GAUGE 14 14
    O.L.D. 100MM 135MM
    AXLE LENGTH 108MM 145MM
    QR N/A N/A
    WEIGHT 180G 415G




    RX-25
    RX-26

  •   6 BOLT DISC
      RX-2611
    SPECIFICATION
    F/R R
    HOLE COUNT 24/28/32H
    GAUGE 14
    O.L.D. 135MM
    AXLE LENGTH 145MM
    QR N/A
    WEIGHT 425G




    RX-2611

  •   6 BOLT DISC
      CX-20 CX-22
    SPECIFICATION
    F/R F R
    HOLE COUNT 24/28/32H 24/28/32H
    GAUGE 14 14
    O.L.D. 100MM 135MM
    AXLE LENGTH 108MM 145MM
    QR N/A N/A
    WEIGHT 180G 418G




    CX-20
    CX-22
